Product Details:
|
| Operation Range: | Dia 600m | Color: | Yellow / Orange |
|---|---|---|---|
| Rotating Speed: | 0/100/300/600 R.p.m. | Scanning Angle: | 0/10°/45°/90°/180° |
| Idode: | Red Beam Laser | IP: | IP54 |
| Highlight: | laser level surveying equipment,laser level measurement instruments |
||
Feature
* Electronic self-leveling, wide leveling range, high precision and stability.
* With scanning function.
* With clockwise and counterclockwise rotating function.
* Manually with dual axis slope adjustment. +/-5degree for adjusting.
* High impact composite housing with protective rubber overmolding
* Full function IR remote control.
* H.I. (elevation) alert with separate switch.
| Leveling Accuracy | Horizontal ±20″ |
| Leveling Range | ±5° |
| Measuring Range | Diameter 600m (with detector) |
| Spinning Speed | 0,100,300,600 r.p.m. |
| Directional Scanning Angle | 0,10°, 45°, 90°, 180° |
| Slope Setting | ±5°(dual-slope) |
| Light Source | Laser Diode, wavelength:635nm |
| Remote Range | about 20 m |
| Working Temperature | －20℃--＋55℃ (－4℉--＋131℉) |
| Power Supply | DC 4.8-- 6V(NI-MH rechargeable battery pack) |
| Continuous Working Hour | about20 hours |
| Water-proof | IP 54 |
| Dimension | 222(L)X 171(W)X 226(h)mm |
| Weight | 3.8kg |
